概述：(Brief Introduction)　　BXJ/B系列防爆接線盒，是按新電氣設備標準GB3836.1-83爆炸性環境用防爆電氣設備通用要求，GB3836.2-83爆炸性環境用防爆電氣設備，隔爆型電氣設備“d”、GB1336-77防爆電氣設備制造檢驗規程進行設計和制造的，并經防爆檢測單位檢定取得了防爆合格證書。該產品適用于石油、化工、制藥等工廠中具有爆炸性混合物Q-1級場所。合格證書號：GYB99105　　The BXJ/B Serial Explosion-proof wire Connection Box is desiqned and produced in accordance with some items of GB3836.1-83 and GB1366-77. The cerrificale explosion-prood has gained from national explosion-proof inspection test department,It's widely used in the field od oil, chemistry anf pharmacy,where there is Q-1 explosive mixture.Cerificate:No GYB99105
	工作條件：(Worling Conditions)a：海拔高度不超過1000米 a:Less than 1000m above sea levelb：周圍環境溫度： b:Surroundind tempeature:c：空氣相對濕度不大于95％（在25 時） c:Relative humidity less than 95%(at +25 )d：可石油在Q-1級，Q-2級爆炸性氣體混合物的場所。d:For the area of Q-1 or Q-2 explosive gas mixture結構和性能：(Structure and function)a：該系列防爆接線箱殼體為鑄鋁合金，表面噴平紋漆，光潔美觀，隔爆隔爆面經氧化處理具有防腐能力a：The cover body is made of aluminium alloy with smooth painting.The esplosion separation face is very anticorrosive after oxisation treatment.b：接線箱進、出口線口采用壓緊螺母式橡膠密封結構，箱體與蓋板間采用螺紋式隔爆結構，箱體內外分別設有接地螺釘，結構緊湊，安全可靠。b:The mouth or wire-conneeting box is sealed with tightened rubber and there are ground screw inside and outside box for security.c：接線箱結構形式分電纜分布線和鋼管布線兩種。c:The box can be used for both cable and steel pipe.
